Key Features
GL550 Sensored Brushless FOC Motor
1. Adopts advanced FOC (Field-Oriented Control) drive, Finer Linearity.
2. Special rotor winding process with explosion-proof, high precision balance for increasing rotor’s service life and high-speed stability.
3. High precision bearings, reinforced alloy aluminum shell and high toughness stainless steel shaft improves motor’s structural performance.
4. Innovative waterproof design at driving end achieves excellent waterproof and dust-proof performance.
| Name | GL550 Motor For RC Car | |
| Type | FOC | |
| KV | 3300KV | |
| Cells | 2~3S | |
| No-load Current | ≤4.6A | |
| Outer Diameter/Length | Ø36mm(1.417in)/L62.6mm(2.465in) | |
| Shaft diameter/ End length of shaft | Ø5mm(0.197in)/L16mm(0.63in) | |
| Bearing Front(driving end) | D13*d5*T4 | |
| Bearing Rear(wire outlet end) | D15*d6*T5 | |
| Weight | 270 g | |
| Pairs of Poles | 2 Pairs of poles | |
| Application | 1/8 Crawler, 1/10 Crawler | |
